3EAD19XMWR1 05 – DOOR, LIT/OPTIONAL

3EAD19XMWR1 05 – DOOR, LIT/OPTIONAL

Written by

in

3EAD19XMWR1 05 – DOOR, LIT/OPTIONAL

Products

Position	Product
1	DOOR, FREEZER (ALMOND)
1	DOOR, FREEZER (COPPERTONE)
1	DOOR, FREEZER (WHITE)
1	DOOR, FREEZER (AVOCADO)
1	DOOR, FREEZER (HARVEST GOLD)
1	DOOR, FREEZER (COFFEE)
1	DOOR, FREEZER (NEW AVOCADO)
1	DOOR, FREEZER (GOLDEN HARVEST)
2	Insert, Handle (Golden Harvest)
2	Insert, Handle (White, Coffee, & Almond)
2	Insert, Handle (New Avocado)
3	RETAINER, TOP
4	RETAINER, BOTTOM
5	CAP, END HANDLE (2)
6	WPL 849806
7	WP849996 Whirlpool Refrigerator Endcap Trim
8	WPL 840847
9	Hole, Plug (White)
10	Cap, Hinge Sleeve (2)
11	Expansion Clip
12	WP488729 Whirlpool Refrigerator Door Screw
13	DOOR, REFRIGERATOR (ALMOND)
13	DOOR, REFRIGERATOR (GOLDEN HARVEST)
13	DOOR, REFRIGERATOR (NEW AVOCADO)
13	DOOR, REFRIGERATOR (COFFEE)
13	DOOR, REFRIGERATOR (HARVEST GOLD)
13	DOOR, REFRIGERATOR (AVOCADO)
13	DOOR, REFRIGERATOR (COPPERTONE)
13	DOOR, REFRIGERATOR (WHITE)
15	Retainer, Door Trim (For Platinum Model Only)
16	WP488787 Whirlpool Refrigerator Screw
18	PANEL, INTERIOR
19	Retainer, Top & Bottom Gasket
20	SCREW
20	W11624204 Whirlpool Screw
21	Retainer Side, Gasket
24	TRIM, SHELF
28	2188405A Whirlpool Refrigerator Door Gasket
30	PANEL, INTERIOR
31	Retainer, Top & Bottom
32	2188404A Whirlpool Refrigerator Door Gasket
33	Shelf Ladder
39	SHELF, CANT
40	WPL 848648
52	WPL 845884
54	WPL 509324
57	CLIP, TUBULAR
58	CLIP, TUBULAR
59	WPL 848307
61	WPL 981087
67	Hole Plug (2)
71	WPL 985098
71	WPL 985106
71	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
71	WPL 848682
71	350956 Whirlpool Spray Assembly
71	KIT, BRUSH TOUCH-UP (HARVEST GOLD) (HI-LITE)
71	WPL 72019
71	Golden Harvest
71	72017 Whirlpool Appliance Touch-Up Paint White
71	WPL 985105
71	799344 Whirlpool Refrigerator Paint
71	WPL 980333
71	350942 Whirlpool Spray Paint
71	WPL 985104
71	WPL 799735
71	WPL 799342
71	WP72107 Whirlpool Touchup
71	WPL 72024
71	Almond (Uncut)
71	Golden Harvest (Uncut)
71	212643 Whirlpool Refrigerator Permagum Sealer
71	511873 Whirlpool Refrigerator Paint
71	WPL 799833
71	WPL 511881
71	paint, spray 13 oz. (coffee)
71	350930 Whirlpool White Spray Paint
71	WP279368 Whirlpool High-Temperature Silicone Rubber Adhesive
71	285006 Whirlpool Spray
71	WPL 799351
71	72032 Whirlpool Touch Up Paint Black
71	72109 Whirlpool Dacor Avocado Touch-Up Paint
71	Leveler (Thinner) (2oz.)
71	Paint, Touch-Up 1/2 Oz. (Coffee)
71	Enamel, New Avocado (1 Qt. Uncut)
71	Enamel, Coffee (1 Qt. Uncut)
71	WPL 799832
71	Enamel, Black (1 Qt. Uncut)
71	CEMENT, ALUMILASTIC (1 1/4 OZ.)
71	606755 Whirlpool Refrigerator Bag
71	876370 Whirlpool Refrigerator Insulation
71	WP505587 Whirlpool Refrigerator Sealer
71	WP542638 Whirlpool Refrigerator Grease
71	TAPE, VINYL (3/4 X 108“)
71	WPL 985107
71	WPL 833504
71	WPL 833503
71	ENAMEL, AVOCADO (HI-LITE) (SHADED AREA) (1 PT. UNCUT)
71	ENAMEL, AVOCADO (BASE COAT) (1 QT. UNCUT)
71	KIT, BRUSH TOUCH-UP (HARVEST GOLD) (BASE)
71	KIT, BRUSH TOUCH-UP (AVOCADO) (HI-LITE)
71	KIT, BRUSH TOUCH-UP (AVOCADO) (BASE)
71	Paint, Spray 13 Oz. (Avocado)
