46-2837-23-02 07 – TRANSMISSION PARTS

Products

Position	Product
1	134735700 Frigidaire Transmission Assembly
2	5303161307 Frigidaire Dryer Seal Assembly
3	THRUST WASHER
4	WCI 3161436
5	WCI 3161437
6	WCI 3161175
7	LGS SPRING-SMALL
8	OIL-TRANSMISSION-1 QUART
9	WASHER-SPACER
11	BEARING-HOUSING/LGS SPRING PKG
12	WCI 3161309
13	SLEEVE-CLUTCH COIL
15	5303161173 Frigidaire Seal Assembly
16	LOWER HOUSING ASSEMBLY (INC 13)
17	DOWEL PIN
18	THRUST WASHER
19	WCI 3161178
20	WCI 3161170
21	WCI 3161169
22	SECTOR GEAR
23	WCI 3161308
24	WCI 3161225
25	PIPE PLUG
26	WCI 3161223
