49-2827-00-01 04 – DOOR PARTS

Products

Position	Product
1	WCI 3281155
2	WCI 3281044
3	SCREW-VALVE
4	131420300 Frigidaire Screw
5	WCI 3281060
6	DOOR HINGE (2)
8	SPACER (2)
9	WCI 3281051
11	SCREW (8)
12	PANEL-OD-WHITE
12	WCI 3281062
13	PNL. – LD – WHITE
13	PNL-ID-ALMD
14	HEAT SHIELD
15	WCI 3281065
16	5366021400 Frigidaire Door Latch & Metal Strike
17	WCI 3821061
18	TRAP-LINT
19	WCI 3281207
19	WCI 3281206
20	CLIP-GUIDE (4)
21	131658800 Frigidaire Dryer Door Catch Repair Kit
22	CLIP
23	WCI 3281177
24	WCI 3281053
25	5303300265 Frigidaire Oven Screw
26	SUPPORT PIN (2)
27	DR-ACCESS-WHITE
27	PNL-ACCESS-ALMD
