4GMVWC400YW1 02 – CONSOLE AND WATER INLET PARTS

Products

Position	Product
NI	10A CORD ADAPTER (EUROPEAN)
NI	10A CORD ADAPTER (BRITISH)
NI	10A CORD ADAPTER (TYPE B)
NI	10A CORD LOCK
1	MAY W10365086
2	CLIP, SPRING
3	Endcap (L.H.)
4	Endcap (R.H.)
5	MAY 8312709
6	MAY W10480701
7	MAY W10420985
8	MAY 1157158
9	SWITCH, ROTARY ENCODER
10	SCREW,8-18 X 3/8
11	MAY W10422755
12	Screw, 10-32 x 5/8
13	ASSEMBLY, KNOB & DIAL (GREY)
14	ASSEMBLY, CONTROL KNOB (GREY)
15	MAY W10285511
16	MAY W10291177
17	MAY W10345523
18	MAY W10339585
19	MAY W10441423
20	MAY W10238347
21	MAY W10117298
22	MAY W10344775
23	Screw
24	MAY W10323734
25	Spring, Clip Knob
26	MAY 359625
27	SCREW
28	MAY W10251309
29	ACCESSORY PARTS, WASHER, HOSE
30	MAY W10194211
30	MAY W10194210
31	MISCELLANEOUS PARTS BAG, CONNECTOR, HOSE -“Y“
32	MISCELLANEOUS PARTS BAG, WASHER, HOSE ADAPTER
