4GMVWX500YW1 02 – CONSOLE AND DISPENSER PARTS

Products

PositionProduct
NI10A CORD ADAPTER (EUROPEAN)
NI10A CORD ADAPTER (BRITISH)
NI10A CORD ADAPTER (TYPE B)
NI10A CORD LOCK
NILINER (NOT A SERVICEABLE PART)
1MAY W10460136
2MAY W10251381
3MAY W10272630
4MAY W10219342
5MAY 8312709
6MAY W10480662
7MAY W10420984
8SCREW
9MAY 1157158
10MAY W10280079
11MAY W10453573
12Screw, 10-32 x 5/8
13HOUSING ASSEMBLY – DISPENSER
14MAY W10240976
15MAY W10240975
16MAY W10368547
17SCREW, DISPENSER HOUSING MOUNTING
18MAY 97787
19MAY W10240946
20MAY W10240960
21MAY W10287478
22SCREW
23MAY W10326923
24CLIP, SPRING
25TENSIONER, FASCIA
26MISCELLANEOUS PARTS BAG, WASHER, HOSE ADAPTER
27MAY W10194211
27MAY W10194210
28CABLE, USER INTERFACE
29MAY 353362
30MISCELLANEOUS PARTS BAG, CONNECTOR, HOSE -“Y“
