4KNED5800TQ1 01 – CABINET PARTS

Products

Position	Product
NI	MAY 279810
1	MAY W10097091
1	MAY W10396179
2	SCREW
3	Screw
5	MAY 3396795
6	PLUG-STRIKE
7	MAY 3396805
8	SCREW, 10-16 X 1/2
9	Clamp, Motor (With Shield)
10	MAY 3406109
11	SCREW
12	PLUG, HINGE HOLES
13	MAY 3405246
14	CLAMP, MOTOR MOUNT
15	MAY 3394083
16	MAY 3392100
17	TERMINAL, BRASS & TINNED (INCLUDES TERMINAL BLOCK SCREW KIT)
18	CABINET (WHITE)
19	Clip, Ground
20	LOCK, FRONT TOP
21	Panel Front Assembly
22	ASSEMBLY, MOTOR (50 HZ)
23	Clip, Felt Pad
24	DOOR CATCH ASSEMBLY
26	BOLT
27	MAY 342055
28	ASSEMBLY, HINGE AND PIN
29	MAY 348780
30	MAY W10131364
31	IDLER ASSEMBLY
32	Hinge, Top
33	Strike, Door
34	MAY 3397659
35	Door, Rear
36	DOOR FRONT
37	Handle, Door (White)
38	MAY 3406129
39	MAY 279393
40	Screw, 8-18 x 5/8 (External Ground)
41	PULLEY, MOROR 60 HZ.
42	Screw, Set
