4KNTW4630DQ0 03 – CONTROLS AND WATER INLET PARTS

Products

Position	Product
NI	10A CORD ADAPTER (EUROPEAN)
NI	10A CORD ADAPTER (BRITISH)
NI	10A CORD ADAPTER (TYPE B)
NI	10A CORD LOCK
NI	LINER (NOT A SERVICEABLE PART)
1	MAY W10725841
2	CLIP, SPRING
3	MAY W10251358
4	MAY W10251355
5	MAY 8312709
6	MAY W10729893
7	MAY W10461159
8	MAY 1157158
9	SWITCH, ROTARY ENCODER
10	SCREW,8-18 X 3/8
11	MAY W10422755
12	Screw, 10-32 x 5/8
13	KNOB ASSEMBLY, TIMER
14	KNOB ASSEMBLY, CONTROL
15	MAY W10285511
16	MAY W10291183
17	MAY W10683676
18	MISCELLANEOUS PARTS BAG, WASHER, HOSE ADAPTER
19	MISCELLANEOUS PARTS BAG, CONNECTOR, HOSE -“Y“
20	MAY W10194210
20A	MAY W10194211
21	ACCESSORY PARTS, WASHER, HOSE
22	MAY W10684972
23	Screw
24	MAY W10251309
25	MAY 353362
