4KSRF22DTA00 10 – UNIT

4KSRF22DTA00 10 – UNIT

Written by

in

4KSRF22DTA00 10 – UNIT

Products

PositionProduct
1Support, Evaporator
2Grommet, Screw
3SCREW
4Clip, Tube (3)
5Spring-Tube
64387491 Whirlpool Refrigerator Insert
7“O“ Ring Seal (4)
8WP4211117 Whirlpool Refrigerator Connector
9Box, Junction
10WP488729 Whirlpool Refrigerator Door Screw
11Cord, Service
12Screw, 8-32 x 3/8
13549193 Whirlpool Refrigerator Power Clamp
14W11624204 Whirlpool Screw
15Air Baffle, Evaporator
16Baffle, Air
17Tray, Evaporator
18Rail, Front
19Screw, 1/4-28 x 1/2 (2)
20489340 Whirlpool Refrigerator Screw
20Screw (Repair)
21Clip, Wire (2)
22Baffle, Air
23Bracket, Motor
24Screw, 8 x 3/8
25833697 Whirlpool Condenser Fan Motor
26681390 Whirlpool Refrigerator Screw
27Fan, Blade
28WP486692 Whirlpool Refrigerator Nut
29Screw, 8-15 x 3/8
30Guard, Fan
31Frame
32Compressor (Includes Items 43, 44, 45, 46, 47, 56, 57 & 58) (Also Order)
33876811 Whirlpool Grommet
35Condenser & Precooler
36Strap
37Clamp, Capacitor
39Grommet (4)
40Clamp (4)
42W10843121 Whirlpool Refrigerator Tube
43Evaporator
44Exchanger, Heat
45Heat Shield
46WP549433 Whirlpool Refrigerator Heater
47Heater, Clamp (4)
48Clamp
49Pan, Drip
50Dampener (2)
51Clamp Tube
52WPW10141625 Whirlpool Refrigerator Screw Assembly
53303776 Whirlpool Dishwasher Screw
54Cover, Terminal
55Overload Spring
56WP2262181 Whirlpool Refrigerator Start Relay
57Overload
58Strap
59Clip (2)
60WP4387489 Whirlpool Refrigerator Bi-Metal Defrost Thermostat
61Clamp
62Wire Connector
63WP245183 Whirlpool Nut
64Relay
65WPL 1108054
66Overload Spring
67Case, Relay
68Spring, Case
69WPL 1118764
70WPL 1108046
71WP489128 Whirlpool Refrigerator Screw
72Capacitor
73Nut
74Washer
74VALVE, ACCESS (5/8“)
74876764 Whirlpool Refrigerator Primary Valve
74978026 Whirlpool Refrigerator Primary Valve
74978027 Whirlpool Refrigerator Primary Valve
74978030 Whirlpool Refrigerator Valve
74WP978025 Whirlpool Refrigerator Valve
74VALVE, ACCESS (1/2“)
