4KSRT26DTA00 08 – REFRIGERATOR SHELF , OPTIONAL

4KSRT26DTA00 08 – REFRIGERATOR SHELF , OPTIONAL

Written by

in

4KSRT26DTA00 08 – REFRIGERATOR SHELF , OPTIONAL

Products

Position	Product
	350930 Whirlpool White Spray Paint
	285006 Whirlpool Spray
	Torx Key
	WPL LIT628107
	WPL LIT879940
	350942 Whirlpool Spray Paint
	Paint, Spray (13 Oz.) (Platinum)
	Toast
	WPL LIT1117671
	WPL LIT1117669
	WPL LIT1117667
	350956 Whirlpool Spray Assembly
	Leveler (Thinner)
1	Shelf Gasket, Glass
2	520965 Whirlpool Refrigerator Support
3	Shelf Ladder (2)
4	Screw, 8 x 1-1/4 (3)
4	Screw, (Repair) 10 x 1 1/4
5	Screw, 8-32 x 1-1/4
5	Screw (Repair)
6	Shelf, Stud
7	Frame-Utility, Cantilever
8	Stud, Shelf (4)
9	Glass, Cantilever Shelf
10	Trim, Frame
11	Reflector, Glass Shelf
12	Stud, Shelf (2)
13	Shelf, Cantilever
14	Trim, Shelf Front
15	Glass, Cantilever Shelf
16	Reflector, Cantilever
17	Frame, Cantilever Rollout
18	Roll Out Shelf, Cantilever
19	Gasket, Rear (2)
20	Screw, Grommet
21	Pan Crisper
22	Glass, Rollout Shelf
23	Reflector, Glass Shelf Rollout
24	Frame, Meat & Crisper
25	Glass, Crisper & Meat Cover
27	Screw (Repair)
27	WP488729 Whirlpool Refrigerator Door Screw
28	Front, Cover Meat Pan
29	Pan, Meat
30	Front Cover, Crisper
32	Light Lens, Lower
33	Stud, Shelf
34	Trim, Frame Crisper & Meat
35	Reflector, Glass
37	Pan Gasket, Front
39	Tray, Utility
40	Front, Utility Tray
42	Egg Container, Bottom
43	212643 Whirlpool Refrigerator Permagum Sealer
43	WPL 72112
43	Egg Container, Top
43	72032 Whirlpool Touch Up Paint Black
43	Platinum (Uncut)
43	Enamal, Toast (1 Qt. Uncut)
43	72113 Whirlpool Touch-Up Paint
43	Almond (Uncut)
43	WP72107 Whirlpool Touchup
43	799344 Whirlpool Refrigerator Paint
43	72017 Whirlpool Appliance Touch-Up Paint White
43	WPL 876029
43	511873 Whirlpool Refrigerator Paint
43	Enamel, Black (1 Qt. Uncut)
43	CEMENT, ALUMILASTIC (1 1/4 OZ.)
43	TAPE, VINYL (3/4 X 108“)
43	WP542638 Whirlpool Refrigerator Grease
43	WP505587 Whirlpool Refrigerator Sealer
43	WP503695 Whirlpool Refrigerator Sealer
43	876370 Whirlpool Refrigerator Insulation
43	833938 Whirlpool Refrigerator Terminal
43	WPL 799832
43	WPL 799833
43	606755 Whirlpool Refrigerator Bag
