4KSRT26DTA00 10 – UNIT

4KSRT26DTA00 10 – UNIT

Written by

in

4KSRT26DTA00 10 – UNIT

Products

PositionProduct
1Evaporator
2W11624204 Whirlpool Screw
3Grommet, Screw
4Support, Evaporator
5SCREW
7Compressor (Includes Items 43, 44, 45, 46, 47, 56, 57 & 58) (Also Order)
8876811 Whirlpool Grommet
9Heater, Defrost
10Clamp, Evaporator
11WP4387489 Whirlpool Refrigerator Bi-Metal Defrost Thermostat
12Clamp
13W11693756 Whirlpool Screw Assembly
14Baffle, Air
15WP486692 Whirlpool Refrigerator Nut
16Fan, Blade
17Clamp
18833697 Whirlpool Condenser Fan Motor
19Bracket, Motor
20681390 Whirlpool Refrigerator Screw
22Box, Junction
23WP488729 Whirlpool Refrigerator Door Screw
24Screw, 8-32 x 3/8
25Wire Connector
26Cord, Service
27549193 Whirlpool Refrigerator Power Clamp
29Tray, Evaporator
30Screw, 8-15 x 3/8
31Strap
32Clip, Wire (2)
33303776 Whirlpool Dishwasher Screw
34Heater, Clamp (4)
35Frame Assembly
36Clip (2)
37Clamp, Capacitor
39case spring
40Case, Relay
41Spring, Overload
42Relay
43Overload
44Clamp
45W10843121 Whirlpool Refrigerator Tube
46Condenser & Precooler Assembly
47Clamp (4)
48Grommet (4)
50Spring-Tube
51Clip, Tube (3)
52Exchanger, Heat
53WPW10141625 Whirlpool Refrigerator Screw Assembly
54Clamp Tube
55Dampener (2)
56Pan, Drip
57Screw, 1/4-28 x 1/2 (2)
59Rail, Front
60489340 Whirlpool Refrigerator Screw
614387491 Whirlpool Refrigerator Insert
62“O“ Ring Seal (4)
63WP4211117 Whirlpool Refrigerator Connector
64Guard, Fan
65Screw, 8 x 3/8
68WP245183 Whirlpool Nut
69Running Capacitor
70WPL 1108046
71WP489128 Whirlpool Refrigerator Screw
72WP2262181 Whirlpool Refrigerator Start Relay
73Overload
74Cover, Terminal
75Strap
76Overload Spring
77Capacitor
78Nut
79978026 Whirlpool Refrigerator Primary Valve
79VALVE, ACCESS (1/2“)
79WP978025 Whirlpool Refrigerator Valve
79VALVE, ACCESS (5/8“)
79Washer
79978030 Whirlpool Refrigerator Valve
79978027 Whirlpool Refrigerator Primary Valve
79876764 Whirlpool Refrigerator Primary Valve
