5KES8556EBK0 03 – FRONT PANEL & USER INTERFACE PARTS

Products

Position	Product
1	PANEL, FRONT (CAST IRON BLACK)
1A	PANEL, FRONT (PORCELAIN WHITE)
1B	PANEL, FRONT (STAINLESS STEEL FINISH)
2	O-RING
3	WIRE, BREW HEAD TO BOILER COVER
4	SCREW
5	SCREW
6	DISPLAY, USER INTERFACE
7	JUMPER, BREW HEAD TO UI
8	JUMPER, UI TO PCBA
9	JUMPER, PIEZO BOARD TO PCBA
