6EB21DKXDW00 04 – SHELF, LIT/OPTIONAL

6EB21DKXDW00 04 – SHELF, LIT/OPTIONAL

Written by

in

6EB21DKXDW00 04 – SHELF, LIT/OPTIONAL

Products

PositionProduct
WPL LIT2177028
Literature Parts (Do-It-Yourself Manual Ref./Frz.)
W11729596 Whirlpool Ice Maker Field Install Kit
Torx Key
WPL LIT677971
WPL LIT2165693
1Shelf, Ladder (2)
2Shelf, Ladder Center
3520965 Whirlpool Refrigerator Support
4Cover
5Screw (3)
6WP489474 Whirlpool Refrigerator Screw
7Frame Assembly, Cantilever (3)
8Shelf, Slide
9Crisper Cover
10Hook, Shelf
11Glass, Crisper Cover
12Shelf, Meat Pan
13Freezer Basket, (Lower)
14Trim, Basket (Lower)
15WP2172748 Whirlpool Drawer Support
16Glass, Shelf
17Freezer Basket, (Upper)
18W10854959 Whirlpool Refrigerator Shelf Stud
19Pan, Crisper
20Meat Pan
21Crisper Gasket, Front
22Rack, Ice Tray
23Trim, Ice Bucket
24Screw
25WP841180A Whirlpool Microwave Glass Turntable Tray
26Ice Bucket
27Slide, Track
28Trim, Basket (Upper)
29WP2179234 Whirlpool Refrigerator Pan Trim
30WP2179342 Whirlpool Refrigerator Slide
31WP2179343 Whirlpool Refrigerator Control Body
32WP2179243 Whirlpool Refrigerator Pan Trim
37WP2177817 Whirlpool Refrigerator Egg Container
38511873 Whirlpool Refrigerator Paint
38350942 Whirlpool Spray Paint
38212643 Whirlpool Refrigerator Permagum Sealer
38350930 Whirlpool White Spray Paint
38Almond (Uncut)
38WP72107 Whirlpool Touchup
38799344 Whirlpool Refrigerator Paint
3872017 Whirlpool Appliance Touch-Up Paint White
38350956 Whirlpool Spray Assembly
3872032 Whirlpool Touch Up Paint Black
38Door Reversal Instructions
38285006 Whirlpool Spray
38WPL 799833
38CEMENT, ALUMILASTIC (1 1/4 OZ.)
38TAPE, VINYL (3/4 X 108“)
38WP542638 Whirlpool Refrigerator Grease
38WP505587 Whirlpool Refrigerator Sealer
38WP503695 Whirlpool Refrigerator Sealer
38876370 Whirlpool Refrigerator Insulation
38WPL 876029
38606755 Whirlpool Refrigerator Bag
38W10136387A Whirlpool Refrigerator Egg Container
38833938 Whirlpool Refrigerator Terminal
