6ED20TKXDW02 08 – CONTROL, LIT/OPTIONALadmin2025-04-26T12:19:53+00:006ED20TKXDW02 08 – CONTROL, LIT/OPTIONAL ProductsPositionProductWPL LIT2195039Torx KeyWPL LIT2198381WPW10190943 Whirlpool Refrigerator IcemakerWPL LIT21829551Control Box2Mounting Bracket3Screw (2)4WP2149705 Whirlpool Refrigerator Door Switch5WP2175210 Whirlpool Refrigerator Shroud6Defrost Timer (10 Hr.)7489392 Whirlpool Refrigerator Screw8940014 Whirlpool Refrigerator Primary Button Plug9WP2198202 Whirlpool Refrigerator Temperature Thermostat10WP965173 Whirlpool Dishwasher Screw11WP2182195 Whirlpool Refrigerator Cam121110560 Whirlpool Refrigerator Bearing13WP489478 Whirlpool Refrigerator Screw14WP2196062 Whirlpool Refrigerator Clip15Pivot Arm16627068 Whirlpool Refrigerator Screw174387478 Whirlpool Refrigerator Light Socket18Washer19WP67002552 Whirlpool Refrigerator Light Bulb20Control Box Harness21WP1115374 Whirlpool Refrigerator Clip22CLIP, WIRING23Connecting Rod24Fastener, Push-On25Escutcheon, Control Box262182111 Whirlpool Refrigerator Thermal Knob27Knob, Air Control29489203 Whirlpool Refrigerator Washer30WP2196003 Whirlpool Refrigerator Bar Riser31350956 Whirlpool Spray Assembly3172017 Whirlpool Appliance Touch-Up Paint White31876370 Whirlpool Refrigerator Insulation31350930 Whirlpool White Spray Paint31799344 Whirlpool Refrigerator Paint31WP72107 Whirlpool Touchup31Hole Plug31Almond (Uncut)3172110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz31350942 Whirlpool Spray Paint31511873 Whirlpool Refrigerator Paint31606755 Whirlpool Refrigerator Bag31833938 Whirlpool Refrigerator Terminal31WP503695 Whirlpool Refrigerator Sealer31WP505587 Whirlpool Refrigerator Sealer31WP542638 Whirlpool Refrigerator Grease31Golden Harvest (Uncut)31TAPE, VINYL (3/4 X 108``)31CEMENT, ALUMILASTIC (1 1/4 OZ.)31Enamel, Black (1 Qt. Uncut)31WPL 79983331WPL 87602931Golden Harvest3172032 Whirlpool Touch Up Paint Black31285006 Whirlpool Spray31212643 Whirlpool Refrigerator Permagum Sealer
