6LA5800XTG1 04 – AGITATOR, BASKET AND TUB

6LA5800XTG1 04 – AGITATOR, BASKET AND TUB

Written by

in

6LA5800XTG1 04 – AGITATOR, BASKET AND TUB

Products

PositionProduct
1WP3355758 Whirlpool Agitator Cap
2WP358237 Whirlpool Agitator Bolt
3WP3348752 Whirlpool Agitator Mover
5AGITATOR
6W10880720 Whirlpool Tub Ring
7WP3976308 Whirlpool Tub Seal
8WP21366 Whirlpool Spanner Nut
9W10389328 Whirlpool Basket
10285868 Whirlpool Washer Filter Plug Kit
113361596 Whirlpool Outer Tub Primary
12Lock, Filter
13WP389140 Whirlpool Drive Block or Bell
14W10814296 Whirlpool Washer Center Post Seal Gasket
15WP353244 Whirlpool Hose
16WP596669 Whirlpool Hose Clamp
17Hose, Bleach
1880040 Whirlpool Washer Agitator Dog Kit
19Seal, Agitator
20WPW10074580 Whirlpool Agitator Inner Cap and Seal
21WPW10072840 Whirlpool Seal Assembly
22285811 Whirlpool Washer Agitator Repair Kit
23285587 Whirlpool Thrust Washer
