72-3651-23-04 07 – LOWER BODY PARTS

72-3651-23-04 07 – LOWER BODY PARTS

Written by

in

72-3651-23-04 07 – LOWER BODY PARTS

Products

PositionProduct
*85004WCI 3015371
*85004WCI 08010570
*85004WCI 19100220001
1SPACER-BODYSIDE, (8)
3316116400 Frigidaire Oven Light Socket
4316538904 Frigidaire Oven Lamp Light
5Hinge,oven door ,(2)
6A5304534000 Frigidaire Cord
6WCI 3131570
7WCI 3203082
8WCI 3131660
9CLIP-WIRE
10WCI 3131904
11316542102 Frigidaire Flue Gasket
12WCI 08067757
13WCI 3011597
14WCI 5303269543
14AWCI 5303269545
15SCREW-LEVELING
16316067902 Frigidaire Oven Rack
17BINSUL – OVEN BACK (NON-ILLUSTRATED)
17AINSULATION, OVEN WRAPPER
17BTTM-OVEN
185303284616 Frigidaire Range Bulb Clip Thermostat
18AWCI 08067961
19A3131903 Frigidaire Door/Drawer Bumper
19B316064600 Frigidaire Oven Support
19316539800 Frigidaire Oven Retainer
20WCI 5303270160
20ACOVER-POWER CORD, (NON-ILLUSTRATED)
21ACOVER-OVEN FRONT
213203010 Frigidaire Clip
22BINSUL-WOOL
22WCI 5303208642
22DSHIELD-HEAT
22C316282700 Frigidaire Oven Screw
22ATUBE-POST LH
23AANTI-TIP KIT (NOT ILLUSTRATED)
23COVER-IGNITOR
24WCI 5303271606
