72-3651-23-05 07 – LOWER BODY PARTS

72-3651-23-05 07 – LOWER BODY PARTS

Written by

in

72-3651-23-05 07 – LOWER BODY PARTS

Products

PositionProduct
*10554NUT, T,TYPE, LEVELING SCREW (NOT ILLUSTRATED)
*10554WCI 19100220001
1SPACER-BODYSIDE, (8)
3316116400 Frigidaire Oven Light Socket
4316538904 Frigidaire Oven Lamp Light
5Hinge,oven door ,(2)
6A5304534000 Frigidaire Cord
6WCI 3131570
7WCI 316029405
8WCI 3131660
9CLIP-WIRE
10WCI 3131904
11316542102 Frigidaire Flue Gasket
12WCI 08067757
13WCI 3011597
14WCI 5303269543
14AWCI 5303269545
15SCREW-LEVELING
16316067902 Frigidaire Oven Rack
17PANEL-OVEN BOTTOM
17BWCI 316054200
17AINSULATION, OVEN WRAPPER
18AWCI 08067961
185303284616 Frigidaire Range Bulb Clip Thermostat
19316539800 Frigidaire Oven Retainer
19A316064600 Frigidaire Oven Support
20BASE-BROIL
20ACOVER-POWER CORD, (NON-ILLUSTRATED)
21ACOVER-OVEN FRONT
213203010 Frigidaire Clip
22DSHIELD-HEAT
22BINSUL-WOOL
22C316282700 Frigidaire Oven Screw
22WCI 5303208642
22ATUBE-POST LH
23AANTI-TIP KIT (NOT ILLUSTRATED)
23COVER-IGNITOR
24WCI 5303271606
