72-7989-66-03 05 – LOWER OVEN DOOR PARTS

Products

Position	Product
*37931	5303300265 Frigidaire Oven Screw
*37931	SCREW DOOR MTG
1	BRACKET-GLASS MTG
2	GLASS-OVEN DOOR, HEAT BARRIER, (2)
3	WCI 5303209511
4	GLASS FRNT
5	HANDLE
6	WCI 5303209515
7	5303131601 Frigidaire Oven Seal
8	SHIELD-INSULATION
10	WCI 5303211058
11	WCI 5303209517
12	FASTNR-NYLN SPACER 9/16``
13	SEAL-ROPE, 0.25 DIA
14	WCI 3106851
15	GLASS-OVEN DOOR, INNER
16	INSULATION-OVEN DOOR
17	5303208655 Frigidaire Reflector Assembly
18	REFLECTOR, ALUMINUM FOIL
19	SEAL, FOAM (4)
