73-3957-00-08 08 – LOWER BODY PARTS

73-3957-00-08 08 – LOWER BODY PARTS

Written by

in

73-3957-00-08 08 – LOWER BODY PARTS

Products

PositionProduct
*44038WCI 19100230001
*440383203550 Frigidaire Oven Plug
1SPACER-BODYSIDE, (8)
3APNL-BODYSIDE RH-WHITE
3PNL-BODYSIDE LH-WHITE
4WCI 08067749
5WCI 08067757
6WCI 3203082
7SHIELD-REAR WALL, LOWER
8COVER-ACCESS
9COVER-FLUE
10316067902 Frigidaire Oven Rack
11SCREW-LEVELING
12WCI 3131570
13SHIELD, OVEN BOTTOM
14WCI 316007002
15PANEL-OVEN BOTTOM
16WCI 5303051385
17PAN-BROILER
18WCI 5303131356
195304409888 Frigidaire Oven Terminal Block with Hardware
20PLATE-GROUND STRAP
21WCI 08067754
223051162 Frigidaire Oven Range Front Broiler Drawer Glide
23WCI 3051367
245304524341 Frigidaire Lens
25316403803 Frigidaire Insulation
26WCI 3051344
26AWCI 3131104
27DSCREW-HINGE MTG. (6) (NON-ILLUSTRATED)
27C3131903 Frigidaire Door/Drawer Bumper
27AINSULATION, OVEN WRAPPER
27RETAINER-GLASS
27E316205500 Frigidaire Oven Nut
27BINSULATION OVEN BACK (NON-ILLUSTRATED)
28WCI 3017396
29WCI 3203218
30WCI 5308010597
30AWCI 08013188
31SHIELD-LATCH
32SHIELD-LATCH (NON-ILLUSTRATED)
33FSTNR-PUSH ON
34WCI 08067781
36316116400 Frigidaire Oven Light Socket
37316538904 Frigidaire Oven Lamp Light
38WCI 08067810
39RETAIN, CATALYST
40SWITCH-OVEN LITE DOOR
41WCI 5303131289
42WCI 5303209316
45BSHIELD, HEAT, BODY SIDE (NOT ILLUSTRATED)
45WCI 3200848
45CFASTENER-EDGE MTG (NOT ILLUSTRATED)
45AINSULATION, OVEN TOP
46WCI 5303208642
46BANTI-TIP KIT (NOT ILLUSTRATED)
46ATUBE-POST LH
47WCI 3203582
