76-4960-23-01 08 – LOWER BODY PARTS

76-4960-23-01 08 – LOWER BODY PARTS

Written by

in

76-4960-23-01 08 – LOWER BODY PARTS

Products

PositionProduct
*53402WCI 5303269971
*5340108067973 Frigidaire 0 Insulation
*53401INSULATION OVEN BACK (NON-ILLUSTRATED)
*53401WCI 08068018
*53401SHIELD, HEAT, BODY SIDE (NOT ILLUSTRATED)
*53401SHIELD-LATCH
*53402ANTI-TIP KIT (NOT ILLUSTRATED)
*534013131903 Frigidaire Door/Drawer Bumper
*53401INSULATION, OVEN WRAPPER
*53401INSULATION, OVEN TOP
*53402PLATE-RECEPTACLE
*53402WCI 597T040P01
*53402WIRING DIAGRAM
*53401316064600 Frigidaire Oven Support
*53400WCI 08067992
*53400STUD SPACER (2) (NON-ILLUSTRATED)
*53403WCI 19100240004
*53400SHIELD-LATCH (NON-ILLUSTRATED)
*53400WCI 08013188
1SPACER-BODYSIDE, (8)
3316116400 Frigidaire Oven Light Socket
4316538904 Frigidaire Oven Lamp Light
5WIRE, GLASS RETAINER
65304524341 Frigidaire Lens
7WCI 316007002
8WCI 3131570
9SHIELD-HEAT UPPER
10WCI 3131313
115303284616 Frigidaire Range Bulb Clip Thermostat
12WCI 3131672
13FSTNR-PUSH ON
14WCI 3203082
15WCI 5303209316
16316282700 Frigidaire Oven Screw
17SWITCH-OVEN LITE DOOR
18WCI 5303131289
19WCI 5303269502
20WCI 08067991
21CLIP-WIRE
22WCI 3131931
23316542102 Frigidaire Flue Gasket
24WCI 3203218
25WCI 5303015453
26WCI 5303131357
27WCI 08067757
28WCI 3011597
29SHIELD-FRONT
30SHIELD-OVN TOP
31WCI 3200836
32AWCI 5303269545
32WCI 5303269543
33316067902 Frigidaire Oven Rack
34WCI 5303131356
35PAN-BROILER
36BTTM-OVEN
373051162 Frigidaire Oven Range Front Broiler Drawer Glide
38WCI 3200594
39WCI 08067961
40WCI 5303271660
41WCI 5303271454
42TRIM – VERTICAL B/S (2)
43SCREW-LEVELING
44WCI 5303269934
45WCI 5303269933
46WCI 5303269935
47WCI 3015371
