76-4967-00-12 04 – LOWER OVEN DOOR PARTS

Products

Position	Product
*40736	5303208655 Frigidaire Reflector Assembly
*40736	REFLECTOR, ALUMINUM FOIL
*40735	SEAL, FOAM (4)
1	WCI 08067996
2	WCI 5303051148
3	GLASS PKG
4	GLASS FRNT
5	HANDLE
6	LINER
7	5303131601 Frigidaire Oven Seal
8	WCI 3202151
9	SUPPORT, GLASS
10	WCI 3131128
11	CLIP-RETAINING
12	FSTNR. SPACER (6)
13	WCI 3016851
13A	WCI 08010463
14	INSUL OV DR W/ FOIL
