77-4950-23-04 04 – LOWER BODY PARTS

Products

PositionProduct
*79033STUD SPACER (2) (NON-ILLUSTRATED)
1SPACER-BODYSIDE, (8)
3WCI 5303269545
3AWCI 5303269543
4WCI 5303271658
5WCI 08067757
6WCI 3203082
7SHIELD-REAR WALL, LOWER
8COVER-ACCESS
9COVER-FLUE
10316067902 Frigidaire Oven Rack
11SCREW-LEVELING
12WCI 3131570
13SHIELD, OVEN BOTTOM
14WCI 316007002
15PANEL-OVEN BOTTOM
17PAN-BROILER
18WCI 5303131356
195304409888 Frigidaire Oven Terminal Block with Hardware
20PLATE-GROUND STRAP
21WCI 08067754
223051162 Frigidaire Oven Range Front Broiler Drawer Glide
23WCI 3051367
245304524341 Frigidaire Lens
25316403803 Frigidaire Insulation
26WCI 3051344
27RETAINER-GLASS
27HWCI 3015418
27CINSULATION, OVEN TOP
27AINSULATION, OVEN WRAPPER
27GWCI 5303206618
27BINSULATION OVEN BACK (NON-ILLUSTRATED)
27FWCI 3051299
27E3203550 Frigidaire Oven Plug
27D316205500 Frigidaire Oven Nut
28WCI 5303015361
29WCI 5303131357
30WCI 3203218
30AWCI 08013188
31SHIELD-LATCH
32SHIELD-LATCH (NON-ILLUSTRATED)
33FSTNR-PUSH ON
34SWITCH-LATCH
36316116400 Frigidaire Oven Light Socket
37316538904 Frigidaire Oven Lamp Light
38WCI 08067810
39WCI 08010606
40SWITCH-OVEN LITE DOOR
41WCI 5303131289
42WCI 5303269501
45A3131903 Frigidaire Door/Drawer Bumper
45WCI 3200848
46TRIM – VERTICAL B/S (2)
47WCI 5303269933
48WCI 5303269934
48ASHIELD, HEAT, BODY SIDE (NOT ILLUSTRATED)
48BFASTENER-EDGE MTG (NOT ILLUSTRATED)
48CANTI-TIP KIT (NOT ILLUSTRATED)
49WCI 3203582
50WCI 5303269935
50AWIRING DIAGRAM-(NOT FOR PURCHASE) (NON-ILLUSTRATED)
51COVER-LIGHT/SWITCH ROD
