8518L30 04 – MOTOR, HEATER AND SPRAY ARM

Products

Position	Product
1	Attach Clip
2	Screw No.8Bx5/16“ Lg.C.R. Truss Hd. St. St.
3	Drain Hose
4	Shim
5	Strike
6	WP22001496 Whirlpool Screw
7	Gasket Clip
8	Sealing Washer
9	Washer
10	Roller
11	Shoulder Screw
12	Nut
13	Float
14	Screw No.10×1“Lg. Hex Washer Hd. St. St.
15	Tub Assembly
16	Plate – Float Tube
17	Gasket – Float Tube
18	Counterbalance Guide-L.H.
19	Nut
20	Gasket Clip
21	WP250830 Whirlpool Refrigerator Screw
22	“O“ Ring
23	Counterbalance Arm Guide R.H.
24	Wire-Gasket Junction
25	Gasket & Wire Assembly (Includes Item 24)
26	Float Assembly
27	Switch
28	Screw 4-40×5/8“ Lg. Hex Hd. Cad. Pl.
29	Gasket-Water Inlet
30	Water Inlet Assembly
31	Clamp
32	Tubing-Inlet
33	Cage Nut
34	Tapping Plate
35	Shim-Clip
