8518L40 05 – RACK

Products

Position	Product
1	Screw No.10-32×2“Lg. Hex Hd. St. St.
2	Washer
3	Heater
4	Impeller – Upper
5	Blade – Macerator
6	Shroud – Impeller
7	Plate – Pump
8	Gasket – Pump
9	“O“ Ring
10	Impeller-Lower Kit
11	Seal
12	Gasket-Pump
13	Screw No.10×1“Lg. Hex Washer Hd. St. St.
14	Pump Housing
15	Clamp Ring (Includes Both Halves)
16	Slinger
17	Motor (Includes Slinger, 3 Brass Shims, 4 Motor Attach Bolts, 1-2 1/4“ Lg.Impeller Bolt, Motor, Sha
18	Nut 1/2“ 20 Brass
19	Grommet – Heater
20	Gasket – Delivery Arm
21	Baffle Plate
22	Clamp
23	Gage – Seal Shim
24	Seal Installation Tool
25	Water Shield
26	Pump Housing (Includes Diffuser & Plate Spacer)
27	Screw No.10-30Ax1-3/4“Lg. Hex Hd. St. St.
28	Lockwasher No.10 External Teeth
29	Nut
30	Spray Arm Assembly – Lower
31	Washer-Spray Arm
32	Nut
33	Clamp
34	Elbow & Tube Assembly
35	“O“ Ring
36	WP67006908 Whirlpool Refrigerator Screw
37	Spray Arm Assembly
38	Spray Arm Assembly – Upper
39	Spindle – Spray Arm
40	Cotter Pin
