8565L10 13 – DETERGENT CUPadmin2025-04-26T09:50:13+00:008565L10 13 – DETERGENT CUP ProductsPositionProduct1Screw No.10-32x2``Lg. Hex Hd. St. St.2Washer3Heater (Includes Key Nos. 23 & 24)4Impeller - Upper5Blade - Macerator6Shroud - Impeller7Plate - Pump8Gasket - Pump9``O`` Ring10Impeller-Lower Kit11Seal12Gasket-Pump13Screw No.10x1``Lg. Hex Washer Hd. St. St.14Pump Housing15Clamp Ring (Includes Both Halves)16Watershield Fan (Includes Key No. 17)17Tolerance Ring18Motor (Includes Slinger, 3 Brass Shims, 4 Motor Attach Bolts, 1-2 1/4`` Lg.Impeller Bolt, Motor, Sha19Seal Installation Tool20Gage - Seal Shim21WP285655 Whirlpool Hose Clamp22Clamp23Grommet - Heater24Nut 1/2`` 20 Brass25Clamp26Hose27Pump Housing (Includes Diffuser & Plate Spacer)28Screw No.8x5/8`` Lg. C.R. Truss Hd. Cad. Pl.29Clamp30Screw No.10-30Ax1-3/4``Lg. Hex Hd. St. St.31Lockwasher No.10 External Teeth32Nut33Bearing34Spray Arm Nut35Spray Arm Assembly36Tower Base37Tower Section38Tower Tip39Nut40Upper Spray Arm41Distributor42Gasket43Elbow & Tube Assembly
