8565L10 22 – RACK

Written by

8565L10 22 – RACK

Products

Position	Product
1	Detergent Cup & Cover Kit
2	“O“ Ring
3	Screw No. 8 x 5/8“ Lg. Hes Washer Hd. St. St.
4	Cam
5	Spiral Pin
6	Spring – Cam
7	Spring-Cam Compression
8	Nut
9	Trigger Assembly
10	Washer
11	Bushing
12	O-RING
