8624^1B 04 – SHELF

Products

PositionProduct
1Ladder (2)
2Screw, No.8 x 5/8
3Support Shelf
4718257 Whirlpool Dishwasher Screw
5Shelf, Ice Container Lower
7Clip, Shelf Trim
8Pan Crisper
9Cover, Crisper
10Pan Meat
11Cover Crisper Lower
12Shelf, Lower Freezer
13Trim Shelf
14Shelf, Center Freezer
15Grommet, Shelf/Rod Mounting (Right Hand)
16Basket Trim
17Half Shelf Upper
18Insert, Half Shelf
19Basket, Freezer
20Slide, Basket (R.H)
21Slide, Basket (L.H)
22Frame, Cantilever Shelf
23Shelf, Glass
24Trim, Rear Shelf
25Trim, Shelf Front
26Support, Ice Maker
27Screw
