95-1997-23-02 03 – CABINET PARTS

Products

Position	Product
*46063	WCI 08016571
1A	5304455650 Frigidaire Refrigerator Screw
1	WCI 3001496
2	WCI 3001301
3	WCI 3001452
4	WCI 3001028
5	WCI 3001331
6	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
8	WCI 3001217
9	G187559 Frigidaire Refrigerator Bushing
10	WCI 3001226
11A	WCI 0800126
11	COVER-EVAPORATOR COIL
12	PLUG-SHORT TEST HOLE (NON-ILLUSTRATED)
13	WCI 3001328
14	5300158289 Frigidaire Evaporator Fan Motor
15	WCI 3001227
16	BRACKET-CONNECTOR
16A	5304455651 Frigidaire Refrigerator Screw
17	DRAIN TROUGH
18	SUPPORT COIL COVER
19	WCI 3001198
20	WCI 3001286
21	WCI 3001287
22	RING-SEAL
23	WCI 3001458
24	SPOUT-DRAIN TUBE
25	PIN-PUSH
26	CHANNEL-RS & LS
26A	5304455852 Frigidaire Refrigerator Screw
27	CHANNEL-CENTER (NON-ILLUSTRATED)
27A	WCI 08016568
28	WCI 3001412
29	ROLLER-REAR (2)
30	BOLT 1/4-28 (2)
32	ROLLER-FRONT (2)
33	SPRING-ROLLER ADJ (2)
34	SUPPORT-ROLLER (2)
35	SCREW-ROLLER ADJUSTMENT
36	WASHER-NYLON (2)
37	WCI 3001478
38	SHIM-BOTTOM HINGE
39	BRACKET-BOTTOM HINGE
40A	WCI 3007090
40	241710601 Frigidaire Refrigerator Screw
41	5303001321 Frigidaire Refrigerator Lower Hinge Pin
42	WCI 3001299
43	WCI 3001038
44	HINGE BRACKET CENTER
45	SCREW, HINGE (4) NO. 10-24 X 7/8
46	PIN-CENTER HINGE
47	TRIM, CAB. COR. ALMD (4)
48	WCI 3001298
49	SHIM-TOP HINGE
50	COVER, HINGE-ALMOND
51	BUTTON, PLUG, ALMD (2)
52	WCI 08010092
