A05LE2E2 02 – CABINET PARTS
Written by
in
A05LE2E2 02 – CABINET PARTS
Products
| Position | Product |
|---|---|
| 1 | SHELL |
| 3 | SCREW (8) |
| 4 | SCREW-FRONT LOCKING |
| 5 | NUT |
| 6 | CLIP-CAP. TUBE |
| 7 | WCI 8009018 |
| 8 | PANEL, CONTROL |
| 9 | WCI 8016109 |
| 10 | SEAL |
| 11 | FRONT-COMPLETE |
| 12 | SEAL |
| 13 | LOUVER (12) |
| 14 | HANDLE (2) |
| 15 | CLIP (2) |
| 16 | SCREW (2) |
| 17 | SUPPORT |
