A05LH5E1 07 – WINDOW MOUNTING PARTS

Written by

Products

Position	Product
1	FRAME, E-Z HANDLE
2	GUIDE (2)
3	WCI 8016080
4	WCI 8016090
5	SCREW (2)
6	STOP, SASH
7	SCREW
8	CHANNEL, E-Z HANDLE, R.H.
9	WCI 8016111
10	CHANNEL, E-Z HANDLE, L.H.
11	FRAME AND GUIDES ASSEMBLY
12	SEAL-TOP FRAME HANDLE (NON-ILLUSTRATED)
13	SEAL-SASH
