A3510PPW 04 – TOP ASSY/FRONT PANEL (A3500)

Products

Position	Product
1	MAY 7725P009-60
2	MAY 7725P008-60
2	MAY 7725P007-60
3	MAY 7118P013-60
4	WPY04000035 Whirlpool Surface Element
5	WPY04000036 Whirlpool Surface Element
6	MAY 1430306K
7	MAY 3802F085-80
7	MAY 7118P015-60
8	MAY 3801F243-51
8	MAY 7719P008-60
8	MAY 3801F242-51
9	SPACER, HINGE (MAIN TOP)
9	MAY 7101P290-60
10	SUPPORT UPPER FRONT PANEL
10	MAY 2614F030-09
10	BRACKET, CNTL. PANEL
11	MAY 7404P085-60
11	MAY 7101P280-60
12	WP7403P238-60 Whirlpool Infinite Switch (Small Element)
12	WP7403P239-60 Whirlpool Oven Switch
13	WP74003280 Whirlpool Knob Assembly
14	WP7737P030-60 Whirlpool Knob Switch
15	MAY 7407P015-60
16	MAY 7112P087-60
17	MAY 5170D130-60
17	MAY 5175D053-60
18	MAY 8113P023-60
