ACS802XM 03 – SECTION

Products

Position	Product
1	Door, Exhaust
2	Link, Wire
3	WP965173 Whirlpool Dishwasher Screw
4	Bracket, Shield Capacitor
5	WP488729 Whirlpool Refrigerator Door Screw
6	Bracket, Running Capacitor
7	Capacitor, Running
8	Shroud, Condenser
9	Wall, Dividing Assembly
11	Stop, Exhaust Door
12	WP302868 Whirlpool Screw
13	Tube, Drain
14	Clip
15	Control, Exhaust Assembly
16	Control, Temperature
17	Switch, Rotary
18	Cover, Control Box
19	Guard, Hazard
20	Screw, Machine 6-32 x .175 (4)
21	Clip, Retainer
22	Box, Control
23	Tube, Wire Guard
24	Housing, Blower Wheel
25	Pan, Drain
26	Clamp, Cable
27	Cable, Appliance
28	Retainer, Shroud Cover
29	212643 Whirlpool Refrigerator Permagum Sealer
29	Guide, Use & Care
29	WP854334 Whirlpool Air Conditioner Sealing Strip
29	List, Repair Parts
29	Guide, Energy
29	Sheet, Tech & Wiring Diagram
29	Wire, Red, (25 Ft.)
29	WP279368 Whirlpool High-Temperature Silicone Rubber Adhesive
29	WPL 799351
29	Lacquer, Starlight Gray (1/2 Pt. Uncut)
29	Wire, 25“ Roll (White 12 GA.)
29	Insulation, Fiberglass (1/4“ x 24“ x 48“)
29	Wire, 25“ Roll (Black 12 GA.)
