AFR15DAE2 1 – Aparts

AFR15DAE2 1

Products

Position	Product
10	GEN WJ20X0406
20	GEN WJ23X0174
25	GEN WJ94X0513
70	GEN WJ35X0092
73	CLAMP POWER CORD
74	GROMMET CORD POWER
160	CAPILLARY .042 CUT TO 15
160	CAPILLARY .054 CUT TO 16
160	CAPILLARY .031 CUT TO 25
180	GEN WJ74X0083
185	GEN WJ76X0220
186	GEN WJ76X0218
192	GEN WJ03X0215
193	FAN NUT
194	FAN SCREW
196	GEN WJ76X0236
197	BAFFLE
360	GEN WJ70X0166
360	GEN WJ70X0283
361	DAMPER DOOR HINGE CLAMP
363	GEN WJ02X0397
364	GEN WJ14X0096
365	GEN WJ14X0095
400	GEN WJ02X0257
400	GEN WJ02X0258
400	GEN WJ02X0259
402	GEN WJ01X0347
406	GEN WJ79X0302
407	GEN WJ79X0301
408	GEN WJ01X0292
410	GEN WJ43X0333
436	ACCUMULATOR CLAMP
590	GEN WJ79X0232
610	GEN WJ82X0142
615	GEN WJ79X0348
616	GEN WJ79X0286
625	GEN WJ82X0144
701	GEN WJ36X0016
708	GEN WJ01X0445
713	GEN WJ03X0294
801	PLATE
809	TUBE SEAL CLAMP
810	COVER EVAPORATOR
812	GEN WJ76X0216
916	SPACER
952	SCREW 10-16 X 5/8" HEX
