AG28E6RTBA 02 – CABINET PARTS

Products

Position	Product
1	SHELL-CABINET
2	WCI G157582-19
3	HRZNTL LUVR (10)
4	DIRECTING LUVR (2)
5	LINK-HORIZONTAL LOUVER
6	WCI G5226571
7	CAP-RUBBER
9	SCREW-FRT PNL
11	PNL-AIR INTAKE
12	WCI G157868
16	WINDOW PANEL
17	SUPPORT-TOP
18	WCI G149187-04
19	WCI G149356-05
20	SUPPORT-SIDES
21	WCI G149182-05
22	WCI G149187-05
23	WCI G145337-10
24	WCI G149188-03
25	WCI G149392-03
26	BRACE-CROSS SUPPORT
27	WCI G521208
28	WCI G117313
29	WCI G100821
30	SCREW – MOTOR TO DUCT (2)
31	SCREW-MTR DUCT
32	SCREW-BRACE TO BUILDING
33	NUT-MOTOR MTG
34	BRACKET-BASE
35	WCI G100773
36	WCI G100824
37A	INSTL. INSTR (NON-ILLUSTRATED)
38A	KIT-60“ WINDOW (NON-ILLUSTRATED)
39A	KIT-DUCT WRK ADPT (NON-ILLUSTRATED)
40	OWNERS MANUAL (NON-ILLUSTRATED)
41A	WCI G522449-53
42A	WCI G522449-32
