AK16E6RRBA 01 – CABINET PARTS

Products

Position	Product
*81103	WCI G520767-97
*81094	WCI G520620-42
*81024	WCI G519215-29
*81085	INSTALL. INSTRUC.
*81056	WINDOW KIT
*81042	WCI G520769-02
*81051	OWNERS MANUAL (NON-ILLUSTRATED)
*81046	WCI G520679-37
*81098	WCI G520767-02
1	CABINET - SHELL
2	WCI G100821
4	WCI G117313
5	WCI G136381
6	WCI G136378
7	WCI G119621
8	WCI G516729-01
9	WCI G100773
10	TOP FRAME
12	SCREW-FRT PNL
13	WCI G145332-25
14	WCI G99731
15	WINDOW PANEL
16	SEAL-SIDES & BTM
17	WCI G149182-05
18	BRACKET-BASE
19	WCI G105492
20	WCI G149181-03
21	MEMBR-SIDE FRAME (2)
22	WCI G521208
22	154419403 Frigidaire Dishwasher Screw
23	BRKT-SILL SUPT (2)
24	BRKT-TRACK SUPT (2)
25	WCI G145337-10
26	SEAL-BETWN UNIT & SHELL
27	SEAL-TOP FRAME
28	WCI G100824
29	NUT-MOTOR MTG
30	WCI G150486-22
31	WCI G150486-10
