AK2500XZ2 03 – SECTION

AK2500XZ2 03 – SECTION

Written by

in

AK2500XZ2 03 – SECTION

Products

PositionProduct
Diagram, Wiring
Sheet, Tech
Guide, Use And Care
1Cabinet
2WPW10141625 Whirlpool Refrigerator Screw Assembly
3Retainer Pin (Rear Grille)
5Grille, Front
6Lens, Light
7Grille, Rear
8Pan, Condensate
9Screw
10Spacer, Grille
11978030 Whirlpool Refrigerator Valve
11978027 Whirlpool Refrigerator Primary Valve
11WP488729 Whirlpool Refrigerator Door Screw
11WP16123 Whirlpool Washer
11Cap, Condensate Pan
11VALVE, ACCESS (1/2“)
11WP978025 Whirlpool Refrigerator Valve
11Seal, Ring (Access Valve) (20 – Pack)
11No Drip Tape (For Sweating Tubes)
11Lacquer, Starlight Gray (1/2 Pt. Uncut)
11Kit, Evaporator Repair (Aluminum Epoxy)
11VALVE, ACCESS (5/8“)
