AL05A4EVG 03 – ELECTRICAL PARTS

Written by

Products

Position	Product
*26981	CONTROL
*26981	CLIP-RETAINER SENS BULB
*26981	SLEEVE-CAPILLARY TUBE
1	5300265301 Frigidaire Air Conditioner P1 Filter Drier
2	CAPILLARY TUBE (CUT TO 40“)
3	WCI 5303206967
4	NUT
5	WCI G521772
6	TRAY-EVAPORATOR
7	WCI 3002376
8	CONTROL-PANEL
9	SWITCH-5 POS
10	CONTROL
11	STRAP-CAPACITOR
12	WCI 5303001903
