AMS140WKW1 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
*54722	WCI 3916557
*54722	WCI 5303209961
1	WCI 5303276694
1	CLAMP-CONTROL BULB (NON-ILLUSTRATED)
2	WCI 5303209938
3	5303305677 Frigidaire Replacement Filter Dryer Filters
4	WCI 5300185054
4	WCI 08009748
4	5304455650 Frigidaire Refrigerator Screw
5	WCI 08009997
6	WCI 08014590
6	WASHER, NO. 10 STEEL, 7/32 X 7/16 OD (NOT ILLUSTRATED)
7	WCI 5303001288
8	WCI 08009749
8	5304455852 Frigidaire Refrigerator Screw
9	CORD-ELECTRIC POWER
10	5304455651 Frigidaire Refrigerator Screw
10	5303001199 Frigidaire Refrigerator Wiring Harness Clamp
11	5308000039 Frigidaire Refrigerator Screw
11	BRACKET-MTG (4)
11	WASHER, EXT TOOTH LOCK, NO. 10 (NON-ILLUSTRATED)
12	WCI 08001012
12	CLAMP-SUCTION TUBE (NON-ILLUSTRATED)
13	CLIP - COMPRESSOR MTG
14	WASHER-COMPR MTG
15	COMPRESSOR W/ ELECTRICALS
16	WCI 3206126
16	5304500008 Frigidaire Oven Screw
17	218513300 Frigidaire Refrigerator Compressor Mount Grommet
18	WCI 5303276693
19	WCI 5300181105
20	WCI 5303211232
21	WCI 08016583
22	WCI 5303017583
