AR18NS8F7 05 – SYSTEM PARTS

Written by

Products

Position	Product
*10140	5300265301 Frigidaire Air Conditioner P1 Filter Drier
*10140	TUBE-CAPILLARY CUT TO 35“
1	WCI 3018220
2	NUT
3	GROMMET
4	GASKET
5	COVER
6	GASKET-NUT
7	WCI 3002038
8	PROTECTOR – OVERLOAD
9	WCI 3002036
10	WCI 3015457
11	WCI 3015302
12	WCI 3204149
13	KIT-START
14	WCI 3017311
15	CLIP-FRONT TO BASE
