AS182N2K1 02 – CABINET PARTS

AS182N2K1 02 – CABINET PARTS

Written by

in

AS182N2K1 02 – CABINET PARTS

Products

PositionProduct
*30669WCI 5303001844
*30669WCI 5303001775
1SHELL-CABINET
2WCI 5303210207
3WCI 5303002459
4LINK-VERT LOUVER RH
5LINK-VERT LOUVER LH
6FRAME-HORIZ. LOUVER
7WCI 5303014139
8WCI 08017353
9WCI 5303210368
10CLIP-FRONT TO BASE
11SCREW FRONT PANEL (NON-ILLUSTRATED)
12WCI 5300331902
13WCI 5303001984
14WCI 5303210369
15INSERT
