AT35MC2 07 – SOAP DISPENSER (AT35)

Products

Position	Product
NI	NOT REQUIRED PART OR SEE NOTE FUSE (NOT REQUIRED)
001	DISPENSER, SUPPLY (COIN)
002	MAY 24001031
003	MAY 24001032
004	MAY 24001119
005	MAY 24001120
006	MAY 24001776
007	MAY 24001448
008	MAY 24001366
008	BLOCK, INPUT POWER (3 WIRE)
010	MAY 24001426
011	MAY 24001777
012	MAY 24001778
013	MAY 24001430
014	MAY 24001301
015	COVER, JUNCTION BOX
017	MAY 24001433
018	MAY 24001225
019	MAY 24001436
020	MAY 24001434
022	MAY 24001775
023	MAY 24001442
024	MAY 24001552
025	MAY 24001780
026	DOWEL PIN FOR HANDLE
027	MAY 24001767
028	MAY 24001785
029	MAY 24001770
030	MAY 24001789
031	MAY 24001791
032	MAY 24001773
033	MAY 24001795
034	MAY 24001423
035	MAY 24001438
036	MAY 24001282
037	MAY 24001353
038	MAY 24001414
039	MAY 24001342
040	MAY 24001432
041	MAY 24001425
