B6307X0 06 – OVEN AND BROILER DOOR W/GLASS
Written by
in
B6307X0 06 – OVEN AND BROILER DOOR W/GLASS
Products
Position
Product
1
Front Panel-Oven Door w/Glass (Wheat)
1
(Front Panel-Broiler Door w/Glass) (White)
1
(Front Panel-Broiler Door w/Glass) (Almond)
1
(Front Panel-Broiler Door w/Glass) (Wheat)
1
Front Panel-Oven Door w/Glass (White)
1
Front Panel-Oven Door w/Glass (Coppertone)
1
Front Panel-Oven Door w/Glass (Almond)
2
Door Glass-Outer (Oven & Broiler)
3
Insulation Retainer (Broiler Door w/Glass)
3
Insulation Retainer (Oven Door w/Glass)
4
Hex Nut 10-32
5
Hinge Arm Guide (Left)
5
Hinge Arm Guide (Right)
6
Shoulder Rivet
7
Insulation Oven Door (Lower)
7
Insulation – Upper or Lower Door
8
Door Glass-Inner
9
Door Lining (Lower)
9
Door Lining – Upper or Lower Door
10
Screw 10-32×3/8“
11
Retainer-Door Glass (2 Req)
12
WP112432 Whirlpool Nut Assembly
13
Screw 10-32×3/4“
14
Screw
15
Lockwasher
16
Spacer
17
Door Handle
←
