BFD400 02 – SECTION

Products

Position	Product
1	Tube, Restrictor (46.0“ Length)
3	Strainer
4	WPL 951349
5	Condenser
8	Sleeve (4)
9	Spring, Overload
10	Overload, Protector
11	Plate, Compressor
12	Cover, Terminal
13	Retainer, Cover
14	WPL 1159233
15	Screw, 8 x 3/8
16	Seal
17	488660 Whirlpool Refrigerator Nut
18	Screw, 1/4-28 x 1“ (4)
19	Harness, Wiring
20	Grommet (4)
21	Base
22	Roller (2)
23	Pin, Roller (2)
24	Glide (2)
25	Compressor, Service (Complete Assembly)
26	Retainer, Terminal Cover
27	Cover, Terminal
28	WPL 643295
29	Spring, Overload
31	WP855199 Whirlpool Bend Return
32	WPL 1155631
33	Spring, Clip
