BPAC1800AS0 04 – CABINET

Products

Position	Product
1	Cabinet
2	Grommet, Appliance Cable
3	Wire, Ground
4	Screw, 8 x 3/8
5	WP486255 Whirlpool Air Conditioner Nut
6	Screw, 8 x 3/8
7	Plate, Escutcheon
8	Spacer, Escutcheon Plate (2)
9	Knob, Control (2)
10	Front, Cabinet (Assembly)
11	Front, Cabinet
12	Filter, Air
13	Retainer, Filter
14	Seal, Front (Top & Sides)
15	Louver, Vertical
16	Handle, Vertical Louver (2)
17	Screw (2)
18	Louver, Horizontal (Relieved)
19	Clip, Cabinet Front (2)
20	Support, Cabinet (2)
21	Support, Retainer (2)
22	Bracket, Support
23	Angle, Top Mounting
24	Angle (2)
25	Gasket, Sash
26	Board, Filler
27	Bag, Accessory
28	Screw (Window Lock Bracket)
29	Bolt, 1/4 x 3/4 (6)
30	WP120393 Whirlpool Washer Assembly
31	Lockwasher (6)
32	Nut, Hex (6)
33	WP965173 Whirlpool Dishwasher Screw
34	WP308685 Whirlpool Microwave Screw
35	Strip, Seal
36	Seal, Bottom
37	Spacer, Block (4)
38	Gasket, Meeting Rail
39	Bracket
40	Rack, Louver (2)
41	Link, Vertical Louver (2)
42	Louver, Horizontal (Handle)
43	Louver, Horizontal (4)
44	Retainer (4)
45	Clip, Retainer (4)
46	Detent Spring (2)
47	Seal, Front (Bottom)
49	WPW10339879 Whirlpool Wire Tie
50	Cabinet Insulation (Right Side)
50	Cabinet Insulation (Left Side)
50	Insulation Cabinet
51	Seal
