CCS51AEL 02 – CABINET, LINER AND DOOR , LIT/OPTIONAL

Products

Position	Product
	350956 Whirlpool Spray Assembly
	350942 Whirlpool Spray Paint
	Leveler (Thinner) (2oz.)
1	Cabinet
2	Front, Shell
3	Door, Inner
4	Liner, Door
5	Plug, Hinge
6	Strip, Tapping (2)
7	Trim, Door (R.S.)
7	Trim, Door (L.S.)
8	Rail, Door (Right Side)
8	Rail, Door (Left Side)
9	Screw, No.8-32 1/2 (6)
10	Thumbscrew 10-32 x 5/8
11	Screw, 8-32 x 3/8 (2)
12	Liner (Includes No.s 5, 6, 7, 11, 14)
13	Gasket, Bottom
14	Clamp, Hose (2)
15	Gasket
16	WP965173 Whirlpool Dishwasher Screw
17	Nut, Molly
18	Washer
19	Nut, Hex 1/4 (2)
21	Stud, Inner Door Mtg. (2)
22	Thermostat, Well Bin
23	Clip, Panel (16)
24	Pull, Door
25	Panel, Exterior (Toast & Platinum)
25	Panel, Door (White & Black)
25	Panel, Door (Almond & Harvest Gold)
26	Grille (Item 39 Included)
27	WP90767 Whirlpool Screw
28	Hose, 5/8 x 4“ (Connector To Air Gap)
29	W11420408 Whirlpool Refrigerator Ice Scoop
30	Screw, No.10-32 x 3/8
31	Insert, Handle
32	Strip, Gasket
33	WP488729 Whirlpool Refrigerator Door Screw
34	Screw, 10 x 1/2
35	Nut, Well (3)
36	Trim, Door (Lower)
37	Insulation, Door
38	Screw, No.8-32 x 1/2
39	List, Parts
39	WP503695 Whirlpool Refrigerator Sealer
39	Tech Sheet
39	978026 Whirlpool Refrigerator Primary Valve
39	Overlay, Grille
39	WP978025 Whirlpool Refrigerator Valve
39	Grid, Cutter (1-1/4“ – Cubes (Complete Assembly))
39	Instructions, Installation
39	Grid, Cutter (3/4“ – Cubes)
39	Leg, Leveling Kit
39	Ice Deflector Kit
39	Instructions, Owner`s
