CEA1M1WSTA 23 – OVEN AND BODYadmin2025-04-26T08:46:43+00:00CEA1M1WSTA 23 – OVEN AND BODY
Products
| Position | Product |
|---|
| *11642 | WCI K5035920 |
| *11642 | WCI K5099308 |
| 2 | WCI K1315115 |
| 3 | WCI K5138301 |
| 4 | WCI K1324043 |
| 5 | WCI K1323564 |
| 6 | ROD |
| 7 | WASHER, PADDED |
| 8 | INSULATION, WRAP |
| 9 | INSULATION, BACK |
| 10 | WCI K1315110 |
| 11 | SCREW |
| 12 | WCI K1099962 |
| 13 | WCI K1315112 |
| 14 | WCI K1325114 |
| 14 | WCI K1325113 |
| 15 | WCI K1307085 |
| 16 | WCI K5024703 |
| 17 | WCI K1311218 |
| 18 | SCREW |
| 19 | WCI KGM110924 |
| 20 | 08002868 Frigidaire 0 Screw Assembly |
| 21 | BRACKET THERM. BULB |
| 22 | WCI K1315107 |
| 23 | WCI K1315113 |
| 24 | CUP, OVEN LT |
| 25 | 316116400 Frigidaire Oven Light Socket |
| 26 | 5304524341 Frigidaire Lens |
| 27 | RETAINING WIRE |
| 28 | 316538904 Frigidaire Oven Lamp Light |
| 29 | SWITCH, OVEN LIGHT |
| 30 | GUIDE |
| 31 | LEG |
| 32 | RAIL, DWR., RH |
| 33 | WCI K5024601 |
| 34 | WCI K5048203 |
| 35 | BUMPER |
| 36 | GUSSET, BACKGRD (2) |
| 37 | WCI K1311283 |
| 38 | WCI K1266 |
| 40 | STRAP-GROUND |
| 41 | 5304409888 Frigidaire Oven Terminal Block with Hardware |
| 42 | 5304442087 Frigidaire Range Wall Oven Broil Pan and Insert |
| 43 | GRILLE, BROILER |
| 44 | HANGER |
| 45 | 5303051516 Frigidaire Broil Element |
| 46 | RACK (2) |
| 47 | 5303051519 Frigidaire Oven 2600W Bake Element |
| 48 | WCI K1315129 |
| 49 | RAIL, DWR, LH |
| 50 | WCI K5024602 |
| 51 | WCI K1315199 |
| 52 | WCI K5157802 |
| 53 | WCI KGM271166 |
