CEA3M2WSTB 19 – COOKTOP-DOOR-DRAWER

Products

Position	Product
1	WCI K5125202
3	08002868 Frigidaire 0 Screw Assembly
4	WCI K1315632
5	WCI K1315630
5	WCI K1315631
6	316048414 Frigidaire Oven Range Chrome 6" Drip Bowl
7	316048413 Frigidaire Oven Range Chrome 8" Drip Bow
8	318372210 Frigidaire Oven Range 6" 1250W Surface Element
9	5308011964 Frigidaire Surface Element P1
10	WCI K1166376
12	5303935058 Frigidaire Oven Burner Receptacle Kit
13	5308014215 Frigidaire Oven Screw
14	WCI K1315541
15	WCI K1325506
16	CHANNEL ASSY (COMPLETE W/ROLLER & STUD)
17	SPRING
19	RIVET
20	ARM ASSY.
22	AXLE
23	WCI K1309794
25	BUMPER BTM
26	WCI K1312283
27	WCI K1325510
28	WCI K5027201
29	WCI K5027101
29	HANDLE ASSY (INCLUDES STANCHION)
30	WCI K5026807
31	STANCHION-HANDLE (2)
32	SCREW
33	HANDLE – DRAWER (CHROME)
34	GLASS – INNER DOOR
35	WCI K1325509
36	5303013272 Frigidaire Oven Nut
37	WCI K1325096
38	DRAWER
39	WASHER, PADDED
44	GASKET (WITH CLIPS)
45	WCI K1309666
46	GUIDE
47	WCI KGM271482
48	SCREW
49	WCI K1311928
50	WCI K1324236
51	SPACER (4)
52	WCI K1164550
53	WCI K1325686
