CEB1M1WSTB 13 – COOKTOP-DOOR AND DRAWER

CEB1M1WSTB 13 – COOKTOP-DOOR AND DRAWER

Written by

in

CEB1M1WSTB 13 – COOKTOP-DOOR AND DRAWER

Products

PositionProduct
1WCI K5270108
2WCI K1315541
308002868 Frigidaire 0 Screw Assembly
4WCI K1315632
5WCI K1315631
5WCI K1315630
6316048414 Frigidaire Oven Range Chrome 6" Drip Bowl
7316048413 Frigidaire Oven Range Chrome 8" Drip Bow
8318372210 Frigidaire Oven Range 6" 1250W Surface Element
95308011964 Frigidaire Surface Element P1
10WCI K1166379
11WCI K1309666
125308014215 Frigidaire Oven Screw
135303935058 Frigidaire Oven Burner Receptacle Kit
16CHANNEL ASSY (COMPLETE W/ROLLER & STUD)
17WCI K1325629
18WCI K1325512
19WCI K1325494
20WCI K1313983
21SPACER (2)
22WCI K1310071
23WCI K1325686
24MOULDING OUTER GLASS
25WCI K1325510
26GLASS – INNER DOOR
27WCI K1309794
28RIVET
29WCI K1325270
30ARM ASSY.
31AXLE
33SPRING
34DRAWER
35WCI K1325096
37HANDLE
385303013272 Frigidaire Oven Nut
39WCI K1099962
40GUIDE
41SCREW
42GASKET (WITH CLIPS)
43WASHER, PADDED
44WCI K1325501
45WCI K5104201
46WCI K1325509
47WCI K1164550
