CEB1M1WSTB 16 – COOKTOP-DOOR-DRAWER

Products

PositionProduct
1WCI K5270108
308002868 Frigidaire 0 Screw Assembly
4WCI K1315632
5WCI K1315630
5WCI K1315631
6316048414 Frigidaire Oven Range Chrome 6" Drip Bowl
7316048413 Frigidaire Oven Range Chrome 8" Drip Bow
8318372210 Frigidaire Oven Range 6" 1250W Surface Element
95308011964 Frigidaire Surface Element P1
10WCI K1166376
11WCI K1315541
125303935058 Frigidaire Oven Burner Receptacle Kit
135308014215 Frigidaire Oven Screw
15WCI K1323814
16CHANNEL ASSY (COMPLETE W/ROLLER & STUD)
17SPRING
18SPACER (4)
19RIVET
20ARM ASSY.
21WCI K1164550
22AXLE
23WCI K1309794
24WCI K1311928
25BUMPER BTM
26INSULATION
27GASKET (WITH CLIPS)
28GLASS
29HANDLE ASSY (INCLUDES STANCHION)
29WCI K5027102
30WCI K5026807
31STANCHION-HANDLE (2)
32WCI K1317834
32SCREW
33WCI K1317835
34WCI K1309055
35WCI K1309054
365303013272 Frigidaire Oven Nut
37WCI K1325096
38DRAWER
39WASHER, PADDED
40SCREW
41GUIDE
42WCI K1309666
