CES365HZ0 05 – DOOR, LIT/OPTIONAL

CES365HZ0 05 – DOOR, LIT/OPTIONAL

Written by

in

CES365HZ0 05 – DOOR, LIT/OPTIONAL

Products

Position	Product
	Literature Parts (Tech Sheet)
	WPL LIT8052360
	WP3196154 Whirlpool Screw Assembly
	3196696 Whirlpool Clip
	Harness, Wire (Door Switch)
	814381 Whirlpool Pin
	3184020 Whirlpool Oven Wire
	Literature (Installation, Instructions (Template))
	Literature (Instruction, Installation)
	Safer Cooking Tips
	WPL 8053623
	WPL 3196697
	W11396691 Whirlpool Element Receptacle and Wire Kit
	Clip, Ground Wire
	3400964 Whirlpool Oven Clip
1	WPW10016370 Whirlpool Door Trim
1	Trim, Door Top (Almond)
2	WP3196164 Whirlpool Screw
3	Handle, Door (Almond)
3	WPW10202216 Whirlpool Door Handle
4	Liner, Door
5	8522415 Whirlpool Oven Wind Gasket
6	WP9758164 Whirlpool Door Glass
7	Frame, Glass
8	Insulation, Door
9	9761499 Whirlpool Oven Retainer
10	WP8053807 Whirlpool Oven Door Hinge
11	Glass, Outer Door (Almond)
11	WP9762476 Whirlpool Door Glass
13	W10491985 Whirlpool Screw
14	8184859 Whirlpool Range Oven Door Trim Kit (2 Sides, 1 Bottom)
14	8184860 Whirlpool Oven Door Trim
15	Clip, Glass (4)
16	Bracket, Latch
17	WP3400832 Whirlpool Screw
18	WP179051 Whirlpool Screw
19	WP3196925 Whirlpool Clip Assembly
20	WP3196175 Whirlpool Screw
21	Wire (14 Ga. 200 c Brown)
21	1
21	8212471 Whirlpool Oven Paint
21	Grease
21	Golden Harvest
21	8273888A Whirlpool Range Oven Anchor Anti-Tip Bracket Kit
21	18 Ga. 80~c Rating (Red)
21	Wire (12 Ga. 150 c Black)
21	Wire (14 Ga. 150 c Yellow)
21	511873 Whirlpool Refrigerator Paint
21	350942 Whirlpool Spray Paint
21	WPL 72112
21	Platinum (Uncut)
21	Enamal, Toast (1 Qt. Uncut)
21	Paint, Spray (13 Oz.) (Platinum)
21	Toast
21	Golden Harvest (Uncut)
21	72113 Whirlpool Touch-Up Paint
21	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
21	Almond (Uncut)
21	WP72107 Whirlpool Touchup
21	799344 Whirlpool Refrigerator Paint
21	72017 Whirlpool Appliance Touch-Up Paint White
21	350956 Whirlpool Spray Assembly
21	WPL 799832
21	238614 Whirlpool Bumper Hinge
21	WPW10208653 Whirlpool Insulation
21	Wire (14 Ga. 150 c Orange)
21	Wire (14 Ga. 150 c Green)
21	Wire (14 Ga. 150 c Brown)
21	Wire (14 Ga. 150 c Blue)
21	242831 Whirlpool Oven Wire
21	W10355051 Whirlpool Cooktop Cleaner Affresh (10 Oz)
21	Paint, Spray 13 Oz. (Avocado)
21	paint, spray 13 oz. (coffee)
21	Paint, Touch-Up 1/2 Oz. (Coffee)
21	72109 Whirlpool Dacor Avocado Touch-Up Paint
21	285006 Whirlpool Spray
21	Wire, 25“ Roll (White 14 GA.)
21	Wire, 25` Roll (Red 14 Ga.)
21	Wire, 25` Roll (Black 14 Ga.)
21	FOIL, ALUMINUM OVEN (18“ X 25 )
21	350930 Whirlpool White Spray Paint
