CFCS3AE3 05 – SECTION

Products

Position	Product
1	Strap, Bale
2	Cover, Terminal
3	Gasket, Cover
4	Cap, Valve
5	Core, Valve
6	Screw
7	Washer, Flat (4)
8	Compressor, Service
9	Sleeve, Grommet (4)
10	Grommet (4)
11	Condenser
12	Screw, 1/4-20 x 1/2
13	Coil, Solenoid
14	Bonnet Assembly
15	Bushing, Snap
16	Base, Unit
17	WP486579 Whirlpool Air Conditioner Screw
18	Receiver Assembly
19	Drier
20	Washer, Lock
21	Screw
22	Nut (1)
23	Valve, Water
24	Motor, Fan
25	Bracket, Motor
27	Body, Valve
28	Blade, Fan
29	WP487887 Whirlpool Refrigerator Screw
30	Spring, Overload
31	Adapter, Overload
32	Screw, 6-32 x 1/4
33	Overload
34	Seal, Bonnet
35	Plunger
36	Diaphragm
37	Body, Solenoid
38	Strainer
